热轧钢坯喷号识别系统
产品编号：STV7000
该系统为我公司研发的过程智能监控管理系统，可对热轧辊道上的钢坯喷涂号码进行自动检测和识别，将相关信息保存；同时完成关键区域图片的自动存储，形成工件的电子档案，建立产品的“数字名片”。该系统能为企业质检人员和生产管理者提供及时准确的产品信息，提高企业的综合信息管理水平。
1. Online identification for billet spray number.
2. Auto emendation for incomplete number.
3. Cross reference with billet database.
4. Automatically store billet information to the system.
1. Advanced Lighting System
The system has an advanced lighting system. Each camera allocates with two special light sources. The light sources are fixed with filter to provide soft and even light beam. The lighting system can effectively minimize the influence caused by the reflection light from natural light.
2. Advanced Graphic Processing Technology
System uses an adaptive template-matching algorithm, a single character to support multi template pattern. While the system operation, it can automatically learn the font and save them into the database. This provides a high accurate recognition rate.
3. Multi Direction Reading
The system supports to read spray number from different directions. The camera can install at both sides, and collect number information from both sides of the billet at the same time.
4. Hand Input Supported
The system supports hand input to the database. When the system found spray number obscure or missing. The operator can hand input the information to database to avoid continuity of information.
|
Heat-Resistance Temperature |
Environment Temperature |
300℃ |
|
Cooling |
Cooling Medium |
Compressed Air |
|
Pressure |
0.4～0.7 MPa |
|
|
Inlet Temperature |
＜40℃ |
|
|
Flow |
0.5 M³/min |
|
|
Power Supply |
Voltage |
220V AC |
|
Power Consumption |
1000W |
|
